WLCSP-12-ZA1

Package WLCSP-12-ZA1
Pin 6
Dimensions (mm) 1.76×2.26
Thickness (mm) 0.65
Pitch (mm) 0.55
Solder Ball (mm) 0.27
Plating
Product Mass (mg) 4.5
Moisture Sensitivity Level (MSL) 1
Recommend Mounting Reflow
Quantity/Reel (pcs) 3000
Taping Direction E2
Non-use Certificate RoHSⅡ
Non-use Certificate REACH
Non-use Certificate Halogen Free

* Refer to the datasheet for the power dissipation of each product.

WLCSP-12-ZA1

Download (Package dimension, Taping specification, Taping reels dimension, Power dissipation and Land pattern (Foot pattern))

Package information

Products

Category ProductName Datasheet
Switching Drivers NEW
ND1160 		IO-Link Device Transceiver
