小型致动器

Power Supply

AC/DC

Types Product Features
ｰ NJW4790A
(Under Development)		 Quasi-Resonance RCC Controller

DC/DC

Types Product Features
Buck, High Voltage NJW1933 600mA,500kHz,Step-Down Switching Regulator in SOT23
Buck, High Voltage NJW4153 Switching Regulator IC for Buck Converter Current Mode Control with 40V/1A MOSFET
Buck, High Voltage NJW4170 Current Mode Control High Speed Frequency Internal 1A MOSFET Switching Regulator IC for Buck Converter
Buck, High Voltage NJW4175 600mA MOSFET Switching Regulator IC for Synchronous Buck Converter
Buck, High Voltage R1272 34V Input PWM/VFM Step-down DC/DC Controller with PLL Synchronization
Buck, High Voltage R1273 14A 34V Input Step-down DC/DC Converter with Synchronous Rectifier

LDO

Types Product Features
High Voltage NJM7800 3-Terminal Positive Voltage Regulator
High Voltage NJM7800S 3-Terminal Positive Voltage Regulator
High Voltage NJM78L00 3-Terminal Positive Voltage Regulator
High Voltage NJM78L00S 3-Terminal Positive Voltage Regulator
High Voltage NJM78LR05 Series Regulator with Reset Function
High Voltage NJM78M00 3-Terminal Positive Voltage Regulator
High Voltage NJM78M00S 3-Terminal Positive Voltage Regulator
High Voltage NJW4107 45V Io=300mA LDO
High Voltage NR1700 42V Input Externally Adjustable 200mA Voltage Regulator
High Voltage R1526 High Noise Immunity 42V Input 300mA Voltage Regulator
Under 10V NJM12856 1A LDO with Reverse Current Protection / Soft Start / Discharge Function
Under 10V NJM12877 200mA LDO with Reverse Current Protection / Soft Start / Discharge Function
Under 10V NJM12884 500mA LDO with Reverse Current Protection / Soft Start / Discharge Function
Under 10V NJM12888 300mA LDO with Reverse Current Protection / Soft Start / Discharge Function
Under 10V RP130 Low Noise 150mA LDO Regulator
Under 10V RP170 10V Input 300mA LDO Regulator
Under 10V RP171 10V Input 150mA LDO Regulator
Under 10V, Low Noise NR1640 200mA Ultra-low Noise Voltage Regulator
Under 10V, Low Noise NR1641 1A Equipped with Low Power Mode Ultra-Low Noise Low Dropout Voltage Regulator
Under 10V, Low Noise RP112 Low Noise 150mA LDO Regulator
Under 10V, Low Noise RP122 Low Noise and Low Supply Current 400mA LDO Regulator
Under 10V, Low Noise RP123 Low Noise and Low Supply Current 250mA LDO Regulator
Negative-Voltage NJM79L00S 3-Terminal Negative Voltage Regultor

General Block

Voltage Detector / System Reset

Types Product Features
High Voltage NV3600 CMOS compatible, High Output Current Voltage Detectors with SENSE pin
High Voltage R3119 36V Input Voltage Detector with Delay Function or SENSE pin
High Voltage R3150 36V Input Voltage Detector with Detect and Release Delay Function or SENSE pin
Under 10V R3111 10V Input Voltage Detector
Under 10V R3112 Voltage Detector with Delay Function
Under 10V R3114 0.8% Accuracy 0.5V Operating Voltage Detector
Under 10V R3116 0.8% Accuracy 0.5V Operating Voltage Detector with Delay Function
Under 10V R3117 Voltage Detector with SENSE pin
Under 10V R3118 Low Voltage Detector with Individual SENSE Pin and Delay Function

Excitation Circuit

Op-Amp

Types Product Features
High Speed NJM2725 160MHz, 1.4nV/√Hz, High Precision Operational Amplifier
High Speed NJU7047 2ch. 9V/μs High-Speed, Rail-to-Rail I/O CMOS Operational Amplifier
High Speed NJU77582 20MHz, Low noise, Excellent EMI Immunity, Rail-to-rail I/O, Operational Amplifiers

Interface

IO-Link

Types Product Features
Half ND1160 IO-Link® Device Transceiver

OSSD

Types Product Features
High Voltage NJW4820 Single Low Side Switch (Wide Input Range Products)
High Voltage NJW4822 1-Channel Low Side Switch
High Voltage NJW4830 Single High Side Switch
High Voltage NJW4832 1-Channel High Side Switch

Switching/Motor

Bridge Driver

Types Product Features
Full NJU7386 Low Voltage Operation H-Bridge Driver
Full NJU7386A Low Voltage Operation H-Bridge Driver
