光幕

Power Supply

AC/DC

Types Product Features
ｰ NJW4790A
(Under Development)		 Quasi-Resonance RCC Controller

DC/DC

Types Product Features
Buck, High Voltage NJW4128 Switching Regulator IC for Buck Converter Current Mode Control with 40V/2.5A MOSFET
Buck, High Voltage NJW4154 Switching Regulator IC for Buck Converter Current Mode Control with 40V/3A MOSFET
Buck, High Voltage NJW4155 Current Mode Control Internal 1.8A MOSFET Switching Regulator IC for Buck Converter
Buck, High Voltage NJW4175 600mA MOSFET Switching Regulator IC for Synchronous Buck Converter
Buck, High Voltage R1272 34V Input PWM/VFM Step-down DC/DC Controller with PLL Synchronization
Buck, High Voltage R1273 14A 34V Input Step-down DC/DC Converter with Synchronous Rectifier

LDO

Types Product Features
High Voltage NJM7800 3-Terminal Positive Voltage Regulator
High Voltage NJM7800S 3-Terminal Positive Voltage Regulator
High Voltage NJM78L00 3-Terminal Positive Voltage Regulator
High Voltage NJM78L00S 3-Terminal Positive Voltage Regulator
High Voltage NJM78LR05 Series Regulator with Reset Function
High Voltage NJM78M00 3-Terminal Positive Voltage Regulator
High Voltage NJM78M00S 3-Terminal Positive Voltage Regulator
High Voltage NJW4107 45V Io=300mA LDO
High Voltage NR1700
(Under Development)		 42V Input Externally Adjustable 200mA Voltage Regulator
High Voltage R1526 High Noise Immunity 42V Input 300mA Voltage Regulator
High Voltage R1517 36V Input 500mA Low Supply Current Voltage Regulator
High Voltage R1518 36V Input 1A Low Supply Current Voltage Regulator
High Voltage NJW4181 High Voltage Very low current consumption Io=100mA Regulator (Wide Input Range Products)
High Voltage NJW4188 High Voltage Io=1000mA Adjustable Low Dropout Regulator
Under 10V NJM12856 1A LDO with Reverse Current Protection / Soft Start / Discharge Function
Under 10V NJM12877 200mA LDO with Reverse Current Protection / Soft Start / Discharge Function
Under 10V NJM12884 500mA LDO with Reverse Current Protection / Soft Start / Discharge Function
Under 10V NJM12888 300mA LDO with Reverse Current Protection / Soft Start / Discharge Function
Under 10V RP130 Low Noise 150mA LDO Regulator
Under 10V RP170 10V Input 300mA LDO Regulator
Under 10V RP171 10V Input 150mA LDO Regulator
Under 10V, Low Noise NR1640 200mA Ultra-low Noise Voltage Regulator
Under 10V, Low Noise NR1641 1A Equipped with Low Power Mode Ultra-Low Noise Low Dropout Voltage Regulator
Under 10V, Low Noise RP112 Low Noise 150mA LDO Regulator
Under 10V, Low Noise RP122 Low Noise and Low Supply Current 400mA LDO Regulator
Under 10V, Low Noise RP123 Low Noise and Low Supply Current 250mA LDO Regulator

General Block

Voltage Detector/ System Reset

Types Product Features
High Voltage R3152 42V Input Window Voltage Detector
High Voltage R3154 42 V Input Window Voltage Detector with Diagnostic Function
High Voltage R3500 42 V Input 4ch Window Voltage Detector with Diagnostic Function
High Voltage NV3601 CMOS compatible, High Output Current Window Voltage Detector with SENSE pin

Op-Amp

Types Product Features
High Speed NJU7046 1ch. 9V/μs High-Speed, Rail-to-Rail I/O CMOS Operational Amplifier
High Speed NJU7047 2ch. 9V/μs High-Speed, Rail-to-Rail I/O CMOS Operational Amplifier
High Speed NJU7048 4ch. 9V/μs High-Speed, Rail-to-Rail I/O CMOS Operational Amplifier
High Speed NJU77582 20MHz, Low noise, Excellent EMI Immunity, Rail-to-rail I/O, Operational Amplifiers
High Speed NJU77701 Wide-Band, High-Speed, Low-Offset, Low-Noise Rail-to-Rail Input/Output CMOS Operational Amplifier

LED Driver

Types Product Features
High Voltage NJW4615A Constant Current LED Driver with PWM Dimming Control
High Voltage NJW4616 Constant Current LED Driver with PWM Dimming Control
High Voltage NJW4617 Constant Current LED Driver with PWM Control
High Voltage R1580 Constant Current LED Driver
Low Voltage NJW4828-B Parallel Input 8-channel Sink Driver
Low Voltage NJW4829 Serial Input Parallel Output 8-channel Sink Driver

Display

LCD Driver

Types Product Features
For Panel R1200 PWM Step-up DC/DC Converter for PMOLED and General Use with Shutdown Function
For Panel R1202 PWM Step-up DC/DC Converter for White LED/PMOLED and General Use with Shutdown Function
For Panel R1203 PWM Step-up DC/DC Converter for White LED
For Panel R1204 PWM/VFM Step-up DC/DC Converter for White LED/PMOLED and General Use
For Panel R1205 PWM Step-up DC/DC Converter for White LED/PMOLED and General Use
For Panel R1206 PWM Step-up DC/DC Converter for White LED
For Panel R1207 PWM Step-up DC/DC Converter for White LED/PMOLED and General Use
For Panel R1208 PWM Step-up DC/DC Converter for White LED
For Panel R1213 2.5A PWM Step-up DC/DC Converter
For Panel R1286 PWM Step-up/Inverting DC/DC Converter with Synchronous Rectifier for AMOLED/LCD
For Panel R1287 PWM/VFM, Dual-channel Step-up/Inverting DC/DC Converter with Synchronous Rectifier for LCD
For Panel R1290 Triple Output DC/DC Converter for LCD/CCD
For Panel R1293 Multi Power Supply IC with Amplifier for LCD
For Panel R1294 Triple Output DC/DC Converter for LCD/CCD

Contactless Sensor

Touch less

Types Product Features
Touch less Sensor NJL5830R Touchless Sensor

Motion Detect/ Distance Measure

Types Product Features
Microwave Sensor NJR4234 24GHz Distance Measurement Module, Digital Output type
Microwave Sensor NJR4266 24GHz Motion Detector / Doppler Module, Digital Output / Low Profile type
Microwave Sensor NJR4267 24GHz Motion Detector / Doppler Module, Digital Output / High Sensitivity Type
Microwave Sensor NJR4652 60GHz Smart Sensor Micro-module, Digital Output type
